UNPACKING
This product requires assembly.
• Carefully remove the product and any accessories from the box. Make sure that all items listed in the packing list are included.
• Inspect the product carefully to make sure no breakage or damage occurred during shipping.
• Do not discard the packing material until you have carefully inspected and satisfactorily operated the product.
• If any parts are damaged or missing, please call 1-888-266-7096 for assistance.
PACKING LIST
Trimmer Assembly
Grass Deflector Assembly with Screw
Operator’s Manual
WARNING: If any parts are damaged or missing do not operate this product until the parts are replaced. Failure to heed
this warning could result in serious personal injury.
WARNING: Do not attempt to modify this product or create accessories not recommended for use with this product. Any
such alteration or modification is misuse and could result in a hazardous condition leading to possible serious personal injury.
WARNING: Do not connect to power supply until assembly is complete. Failure to comply could result in accidental
starting and possible serious personal injury.
ATTACHING GRASS DEFLECTOR
See Figure 2 - 3.
• Remove supplied screw with a phillips screwdriver from the trimmer head.
• Fit the grass deflector into the slots on trimmer head.
• Turn counterclockwise to lock grass deflector into place.
• Line up the screw hole in the grass deflector with the center hole in the trimmer head.
• Install supplied screw and tighten by turning clockwise with a phillips screwdriver.
Fig. 2
GRASS
DEFLECTOR
SLIDE
OVER HEAD
AND
TURN
COUNTERCLOCKWISE
SCREW
SCREW
HOLE
Fig. 3
8
ASSEMBLY
