12
MAINTENANCE
Impellor replacement
1. Remove the nut from the left hand side of
the impellor shaft.
4. Remove the washer and the screw.
7. Remove the pulley and belt.
10. Withdraw the old/damaged impellor.
Be sure to keep the 2 spacer washers
from the right hand side of the impellor.
11. Insert the impellor shaft in the new
impellor and place the 2 washers on the
right hand side.
12. Place the impellor and shaft back into the
front scoop.
8. Remove the impellor shaft nut from the
right hand side.
9. Withdraw the impellor shaft from the left
hand side.
2. Remove the 10 screws from the side cover. 3. Be sure not to lose the 2 springs.
5. Remove the nut from the impellor shaft.
Remove the 3 screws holding the pulley
support plate.
6. Remove the plate and the two spacer
washers.
1 2 3
4 5 6
7 8 9
10 11 12
spring
spacer washer
spacer washer
washer and screw
