1. SWITCHING ON AND OFF
To switch on the tool, rst engage the chain brake by pulling the guard toward the
auxiliary handle as demonstrated in Fig. D1. The chainsaw guard will move from position
2 to position 1, referenced in Fig. D3, once the chain brake is engaged. Press the lock-off
button, then fully press the on/off switch and hold in this position. The lock-off button can
now be released. (see Fig. D2.)
To switch off, release the on/off switch, or push the hand guard into position 2 as shown in
D3. For more details, please refer to THE CHAIN BRAKE section.
1
2
Pos.1
Pos.2
D2
D1
D3
Operation
WARNING: The battery pack will be too cold to be used if it has
been left in the environment with too low temperature (less than
-20 degrees Celsius) for a long time. The battery pack needs to be
warmed up before use.
