2. INSTALLING AND REMOVING THE BATTERY PACK
Slide the battery pack into tool’s battery port. A simple push and slight pressure will be
sufcient. (See Fig. E1.)
Press the battery pack latch and remove the battery pack from the tool. (See Fig. E2.)
Operation
D
Light ON/ Flash Status
Red on
Defective battery.
Red ash
Battery Temperature Protection.
The temperature of battery pack is
less than 0
o
C (32
o
F) or more than
40
o
C (104
o
F).
Green on
Fully charged.
Green ash
Charging.
CHARGING INDICATOR
This charger is designed to detect some problems that can arise with battery packs.
Indicator lights indicate problems (see table below).
