9
With regular use, the battery pack will need 90 MINUTES or less to fully charge. Allow the battery to fully discharge before
recharging. It is recommended to charge the battery pack every 3 months when not in use.
CHARGING PROCEDURE
3 battery pack
2 status LED
1 power LED
Plug the charger into an AC power outlet.1.
Insert the battery pack (3) into the charge, the power LED (1) will turn red. Make sure the latch and battery are fully
inserted into the charger.
2.
Wait 5 seconds, the status LED (2) will turn red, indicating a connection to the power source and that the battery is
charging.
3.
When the battery has become fully charged, the status LED (2) will turn green. The battery can be stored in the charger,
as long as the charger is not plugged in.
4.
NOTE: During charging operation if the Status LED begins to flash red, indicating that the battery requires replacing.
