YASKAWA CDBR Series User Manual

21
MAIN CIRCUIT
TERMINAL M5
4−M6
MTG HOLE
1.44 (36.5) 0.35 (9)
7.09 (180)
12.48 (317) 13.98 (355) 14.57 (370)
5.45 (138.5)
2.95 (75)
8.66 (220)
(68.5)
7.09 (180)
2.70
1.97 (50)
1.18 (30)
OR MORE
1.18 (30)
OR MORE
2−LEAD WIRE OUTLET
1.38 (35) DIA RUBBER
BUSH
WIRE OUTLET 1.10 (28)
DIA RUBBER BUSH
3.94 (100) OR MORE
4.37 (111)
6.14 (156)
7.87 (200)
3.94 (100) OR MORE
3.86 (98)
Fig. 5 Braking Unit Dimensions in inches (mm) CDBR−4090B, −5110B
2.INSTALLATION
