YASKAWA CDBR Series

22
MAIN CIRCUIT
TERMINAL M6
4−M6
MTG HOLE
1.44 (36.5)
0.35 (9)
8.27 (210)
12.48 (317) 13.98 (355) 14.57 (370)
2.76 (70)
6.16 (156.5)
8.27 (210)
4.67 (118.5)
1.97 (50)
1.18 (30)
OR MORE
9.84 (250)
1.18 (30)
OR MORE
2−LEAD WIRE OUTLET
1.38 (35) DIA RUBBER
BUSH
WIRE OUTLET 1.10 (28)
DIA RUBBER BUSH
3.94 (100) OR MORE
4.37 (111)
6.14 (156)
7.87 (200)
3.94 (100) OR MORE
4.09
(104)
Fig. 6 Braking Unit Dimensions in inches (mm) CDBR−4220B, −5300B
