YASKAWA CDBR Series User Manual

36
R
MC
S
T
M
THRX OFF
ON
MC
SA
12
MC
TRX
TRX
20 18
SA
SA
THR
IM
123
P
1
2
34
VS−616G5
B
MC
≈
≈
0
0
Overload Relay Trip Contact
Level Detection
Braking Unit
Motor
L1 (R) L2 (S) L3 (T)
MCCB
Overload Relay Trip Contact of Braking Resistor Unit
Fault Contact
Braking Resistor Unit (Option)
Short−circuit Bar
(Provided as Standard)
Cooling Fan
(
2)
r (
1)
U (T1) V (T2) W (T3)
3−Phase
Power Supply
200 to 230 V 50/60 Hz
Use sequencer to break power supply side on over- load relay trip contact of braking resistor unit.
Failure to observe this can result in a fire.
∗∗
Where is “E” or “V”. When using the braking resistor unit, set constant L3−04 to “0” (stall prevention selection during decel is disabled). If it is not changed, the inverter may not stop within set decel time.
Ground (200V Class : 100Ω or less
400V Class : 10Ω or less)
Fig. 16 For Models CIMR-G5∗2018 to -G5∗2022 (200 V Class 18.5, 22 kW)
