YASKAWA AC Drive
CH700
Catalog
｜
KAEP C710617 24
Peripheral Device Functions Incorporated
for Minimal Initial Investment
Built
-
in Power Supply
for the Sensor
Separate power supply not required
because the drive provides a 24 Vdc
output
(
150 mA
)
for external sensors.
Oscilloscope Function
With the improved oscilloscope function
performance for the DriveWizard
support tool, adjustments can be made
without the need for external measuring
instruments.
Power supply
24 Vdc Control Power
Input Terminal Standard
Equipped
By using an external 24 VDC power
supply, sequences and fault history
can be checked even when the main
circuit power supply is OFF.
Oscilloscope
10 input terminals
Standard Equipped
OFF
DC24 V
24
Vdc control
power supply unit
SIL3
*
Correspondence
STO Standard Equipped
Two contactors are no longer needed.
:
Safety performance measurement under IEC/
EN
61508
High Performance Control
Even Without an Encoder
The digital frequency reference card DI
-
A3 input terminal can also be used as the
multi
-
function input terminal. PG option
cards and I/O option cards for the 1000
series can also be used.
〔
Applicable up to
75
kW for
200
V Class/
400
V Class
〕
Priority Given to Minimize
Space and Initial Investment
In designing this drive, we thoroughly looked into how far the number of required
peripheral devices and installation space can be reduced.
