YASKAWA AC Drive CH700
Catalog
｜ KAEP C710617 24 ｜
YASKAWA
d
Sp
ecifi
catio
ns
Stan
dar
Item
Specifications
Environment
Area of Use
Indoors
・ chemical gas
:
IEC 60721
-
3
-
3
:
3 C 2
・ solid particle
:
IEC 60721
-
3
-
3
:
3 S 2
Power Supply
Overcurrent Category III
Ambient Temperature
IP20/UL Open Type
:
-
10˚C to +50˚C
IP20/UL Type 1
:
−
10˚C to
+
40˚C
・ Do not use the drive in a location where the temperature changes suddenly to improve the drive reliability.
・ When installing the drive in an enclosure, use a cooling fan or air conditioner to keep the internal air temperature in
the permitted range.
・ Do not let the drive freeze.
・ To install IP 20 /UL Open Type drives in areas with ambient temperatures 㱡 60 ˚C, derate the output current.
・ To install IP 20 /UL Type 1 drives in areas with ambient temperatures 㱡 50 ˚C, derate the output current.
Humidity
95 % RH or less
(
no condensation
)
Storage Temperature
Short-term temperature during transportation is - 20 ˚C to
+
70 ˚C
Surrounding Area
Pollution degree 2 or less
Install the drive in an area without
:
・ Oil mist, corrosive or flammable gas, or dust
・ Metal powder, oil, water, or other unwanted materials
・ Radioactive materials or flammable materials, including wood
・ Harmful gas or fluids
・ Salt
・ Direct sunlight
Keep wood or other flammable materials away from the drive.
Altitude
1000 m or less *
3
Shock
・ 10 Hz to 20 Hz, 1 G
(
9 . 8 m/s
2
)
・ 20 Hz to 55 Hz, Catalog code CH7 0 A 2003 to 2180 , 4002 to 4150
:
0 . 6 G
(
5 . 9 m/s
2
)
,
Catalog code CH70A2215 to 2415, 4180 to 4605
:
0.2 G
(
2.0 m/s
2
)
Standards Compliance
・ UL 61800
-
5
-
1
・ EN 61800
-
3
:
2004 +A 1
:
2012
・ IEC/EN 61800
-
5
-
1
・ Two Safe Disable inputs and 1 EDM output according to ISO/EN 13849
-
1 Cat. 3 Ple ， IEC/EN 61508 SIL 3
Note
:
Used by setting functions to multi
-
function digital output terminals.
Enclosure Protection Design
IP 20 /UL Open Type, IP 20 /UL Type 1
Note
:
Install a UL Type 1 kit on an IP 20 /UL Open Type drive to convert the drive to IP 20 /UL Type 1 .
1
:
Increase the drive and motor capacities.
2
:
200 % is the target value. The value varies depending on the capacity.
3
:
Altitudes over 1000 m and up to 4000 m are possible by derating the output current by 1 % for every 100 m.
Contact Yaskawa or your nearest sales representative for details.
Note
:
1 . Perform Rotational Auto
-
Tuning to achieve specifications listed for Open Loop Vector Control, Close Loop Vector Control and Advanced Open Loop
Vector Control.
2 . Install the drive in an environment matching the specifications in the table above for optimum performance life.
