38 YASKAWA ｜ YASKAWA AC Drive CH700
Catalog
｜ KAEP C710617 24
Fully
-
Enclosed Design and Drive Watt Loss Data
When you install the drive in a control panel, the maximum intake air temperature is 50˚C.
The heatsink can alternatively be mounted outside the control panel, thus reducing the amount
of heat inside the panel and allowing for a more compact set up.
・ Cooling Design for Fully
-
Enclosed Panel ・ Mounting the External Heatsink
・ Ventilation Space
60 ˚C
Fully
-
enclosed panel
Air temperature
at top of panel
－10 to
+
60˚C
Heatsink
IP 20 /UL Open Type
Attachment for
external heatsink
(
Option
)
Heatsink
Side Clearance Top/Bottom Clearance
50 mm min.
Airflow
50 ˚C
Drive intake temperature
－10 to
+
50˚C
Ambient temperature
:
50 ˚C
Mounting surface
Intake air temperature for external heatsink
50 mm min.
30 mm min.
Airflow
Open chassis side
:
50 ˚C
Heatsink side
:
50 ˚C
Use only an IP 20 /UL Open Type for the
external heatsink.
For installing the drive
(
IP 20 /UL Open Type
)
with
capacity of 200 V/ 400 V class 22 kW and above,
be sure to leave enough clearance during
installation for main circuit wiring for maintenance.
Drive Watt Loss Data
200 V Class
Catalog Code CH7 0 A 2
003
005
008
011
014
018
025
033
047
060
075
088
115
145
Rated Output Current A
3.2
5
8
11
14
17.5
25
33
47
60
75
88
115
145
Carrier Frequency kHz
2
2
2
2
2
2
2
2
2
2
2
2
2
2
Watt Loss *
W
Internal
5
9
16
21
27
32
36
53
59
110
134
147
209
265
Heatsink
7
13
27
42
59
74
95
126
155
299
357
467
613
748
Total Watt Loss
12
22
43
63
86
106
131
179
214
409
491
614
822
1013
Catalog Code CH7 0 A 2
180
215
283
346
415
Rated Output Current A
180
215
283
346
415
Carrier Frequency kHz
2
2
2
2
2
Watt Loss *
W
Internal
297
362
459
520
603
Heatsink
935
1144
1508
1769
2216
Total Watt Loss
1232
1506
1967
2289
2819
400 V Class
Catalog Code CH7 0 A 4
002
003
005
006
007
009
015
018
024
031
039
045
060
075
Rated Output Current A
1.8
3.4
4.8
5.5
7.2
9.2
14.8
18
24
31
39
45
60
75
Carrier Frequency kHz
2
2
2
2
2
2
2
2
2
2
2
2
2
2
Watt Loss *
W
Internal
13
12
21
28
35
44
55
63
93
121
132
141
188
188
Heatsink
14
18
32
50
70
86
116
141
206
286
331
365
497
557
Total Watt Loss
27
30
53
78
105
130
171
204
299
407
463
506
685
745
Catalog Code CH7 0 A 4
091
112
150
180
216
260
304
371
414
453
605
Rated Output Current A
91
112
150
180
216
260
304
371
414
453
605
Carrier Frequency kHz
2
2
2
2
2
2
2
2
2
2
2
Watt Loss *
W
Internal
225
275
385
397
564
573
728
976
1118
1272
1495
Heatsink
658
804
1012
1279
1484
1709
2075
2778
3133
3559
4500
Total Watt Loss
883
1079
1397
1676
2048
2282
2803
3754
4251
4831
5995
:
Watt loss is calculated in the following conditions
:
･ 200 V class
:
Input voltage 220 V , power frequency 60 Hz, load ratio 100 %
･ 400 V class
:
Input voltage 440 V , power frequency 60 Hz, load ratio 100 %
Contact your Yaskawa or nearest agent when not calculating watt loss in the above conditions.
120 mm min.
120 mm min.
*
