Option Cards
RoHS compliant. Shipment of factory installed option is available. Contact Yaskawa.
Type
Name
Model
Function
Manual No.
Speed
Reference
Card
Analog Input
AI
-
A 3
Enables high
-
precision and high
-
resolution analog speed reference setting.
・Input signal level
: −
10 to
+
10 Vdc
(
20 k▲
)
，4 to 20 mA
(
250 ▲
)
・ Input channels
:
3 channels, DIP switch for input voltage/input current selection
・ Input resolution
:
Input voltage 13 bit signed
(
1 / 8192
)
Input current 1 / 4096
TOBPC73060078
Digital Input
DI
-
A 3
Enables 16
-
bit digital speed reference setting.
・ Input signal
:
16 bit binary, 4 digit BCD
+
sign signal
+
set signal
・ Input voltage
:
24 V
(
isolated
)
・ Input current
:
8 mA
User
-
set
:
8 bit, 12 bit, 16 bit
TOBPC73060080
Communications
Option
Card
MECHATROLINK
-
II
Interface
SI
-
T 3
Used for running or stopping the drive, setting or referencing parameters, and monitoring
output frequency, output current, or similar items through MECHATROLINK
-
II communication
with the host controller.
Note
:
Use options with software versions of 6108 or later.
TOEPC73060086
SIEPC73060086
MECHATROLINK
-
III
Interface
SI
-
ET3
Used for running or stopping the drive, setting or referencing parameters, and monitoring
output frequency, output current, or similar items through MECHATROLINK
-
III
communication with the host controller.
Note
:
Use options with software versions of 6202 or later.
TOEPC73060088
SIEPC73060088
CC
-
Link Interface
SI
-
C 3
Used for running or stopping the drive, setting or referencing parameters, and monitoring
output frequency, output current, or similar items through CC
-
Link communication with the
host controller.
TOBPC73060083
SIEPC73060083
DeviceNet Interface
SI
-
N 3
Used for running or stopping the drive, setting or referencing parameters, and monitoring
output frequency, output current, or similar items through DeviceNet communication with the
host controller.
Note
:
Use options with software versions of 1114 or later.
TOBPC73060084
SIEPC73060084
PROFIBUS
-
DP Interface
SI
-
P 3
Used for running or stopping the drive, setting or referencing parameters, and monitoring
output frequency, output current, or similar items through PROFIBUS
-
DP communication
with the host controller.
TOBPC73060082
SIEPC73060082
CANopen Interface
SI
-
S 3
Used for running or stopping the drive, setting or referencing parameters, and monitoring
output frequency, output current, or similar items through CANopen communication with the
host controller.
TOBPC73060085
SIEPC73060085
EtherNet/IP Interface
SI
-
EN3
Used for running or stopping the drive, setting or referencing parameters, and monitoring output frequency,
output current, or similar items through EtherNet/IP communication with the host controller.
TOEPC73060092
SIEPC73060092
Modbus TCP/IP Interface
SI
-
EM 3
Used for running or stopping the drive, setting or referencing parameters, and monitoring output frequency,
output current, or similar items through Modbus TCP/IP communication with the host controller.
TOEPC73060091
SIEPC73060091
PROFINET Interface
SI
-
EP3
Used for running or stopping the drive, setting or referencing parameters, and monitoring
output frequency, output current, or similar items through PROFINET communication with
the host controller.
Note
:
The drive is compatible with option software versions 4400 and later.
TOEPC73060089
SIEPC73060089
Monitor
Option
Card
Analog Monitor
AO
-
A 3
Outputs analog signal for monitoring drive output state
(
output freq., output current etc.
)
.
・ Output resolution
:
11 bit signed
(
1 / 2048
)
・ Output voltage
: −
10 to
+
10 Vdc
(
non
-
isolated
)
・ Terminals
:
2 analog outputs
TOBPC73060079
Digital Output
DO
-
A 3
Outputs isolated type digital signal for monitoring drive run state
(
alarm signal, zero speed
detection, etc.
)
・ Terminals
:
6 photocoupler outputs
(
48 V, 50 mA or less
)
2 relay contact outputs
(
250 Vac, 1 A or less 30 Vdc, 1 A or less
)
TOBPC73060081
PG Speed
Controller
Card
Complimentary Type PG
PG
-
B 3
For control modes requiring a PG encoder for motor feedback.
· Phase A, B, and Z pulse
(
3
-
phase
)
inputs
(
complementary type
)
· Max. input frequency
:
50 kHz
· Pulse monitor output
:
Open collector, 24 V, max. current 30 mA
· Power supply output for PG
:
12 V, max. current 200 mA
TOBPC73060075
Line Driver PG
PG
-
X 3
For control modes requiring a PG encoder for motor feedback.
· Phase A, B, and Z pulse
(
differential pulse
)
inputs
(
RS
-
422
)
· Max. input frequency
:
300 kHz
· Pulse monitor output
:
RS
-
422
· Power supply output for PG
:
5 V or 12 V, max. current 200 mA
TOBPC73060076
Resolver Interface for
TS2640N321E64
PG
-
RT3
For control modes requiring a PG encoder for motor feedback. Can be connected to the
TS 2640 N 321 E 64 resolver made by Tamagawa Seiki Co., Ltd. And electrically compatible
resolvers.
The representative electrical characteristics of the TS 2640 N 321 E 64 are as follows.
· Input voltage
:
7 Vac rms 10 kHz
· Transformation ratio
:
0 . 5
±
5 %
· maximum input current
:
100 mArms
· Wiring length
:
10 m max.
TOBPC73060087
Note
:
1 . Each communication option card requires a separate configuration file to link to the network.
2 . PG speed controller card is required for PG control.
