YASKAWA E-II SGM H Series User Manual

3 Specifications and Dimensional Drawings
3.15.3 SGMGH Servomotors (1500min
-1
) With Standard Backlash Gears and Without Brakes (Foot-mounted Type)
3-100
Model
SGMGH-
Gear
Ratio
Foot-mounted Dimensions
mm (in)
Shaft-end Dimensions
mm (in)
Approx.
Mass
kg (lb)
E F G K M N XR XC Z Q QK S T U W
Tap
×
Depth
05AASA6
1/6
75
(2.95)
90
(3.54)
12
(0.47)
40
(1.57)
180
(7.09)
130
(5.12)
45
(1.77)
60
(2.36)
11
(0.43)
35
(1.38)
32
(1.26)
28
(1.10)
7
(0.28)
4
(0.16)
8
(0.31)
M8 × 19
20.5
(45.2)
05AASB6
1/11
75
(2.95)
90
(3.54)
12
(0.47)
40
(1.57)
180
(7.09)
130
(5.12)
45
(1.77)
60
(2.36)
11
(0.43)
35
(1.38)
32
(1.26)
28
(110)
7
(0.28)
4
(0.16)
8
(0.31)
M8 × 19
20.5
(45.2)
05AASC6
1/21
75
(2.95)
90
(3.54)
12
(0.47)
40
(1.57)
180
(7.09)
135
(5.31)
45
(1.77)
60
(2.36)
11
(0.43)
35
(1.38)
32
(1.26)
28
(1.10)
7
(0.28)
4
(0.16)
8
(0.31)
M8 × 19
22.5
(49.6)
05AAS76
1/29
75
(2.95)
90
(3.54)
12
(0.47)
40
(1.57)
180
(7.09)
135
(5.31)
45
(1.77)
60
(2.36)
11
(0.43)
35
(1.38)
32
(1.26)
28
(1.10)
7
(0.28)
4
(0.16)
8
(0.31)
M8 ×19
22.5
(49.6)
09AASA6
1/6
75
(2.95)
90
(3.54)
12
(0.47)
40
(1.57)
180
(7.09)
135
(5.31)
45
(1.77)
60
(2.36)
11
(0.43)
35
(1.38)
32
(1.26)
28
(1.10)
7
(0.28)
4
(0.16)
8
(0.31)
M8 × 19
24.6
(54.2)
09AASB6
1/11
75
(2.95)
90
(3.54)
12
(0.47)
40
(1.57)
180
(7.09)
135
(5.31)
45
(1.77)
60
(2.36)
11
(0.43)
35
(1.38)
32
(1.26)
28
(1.10)
7
(0.28)
4
(0.16)
8
(0.31)
M8 × 19
24.6
(54.2)
09AASC6
1/21
95
(3.74)
115
(4.53)
15
(0.59)
55
(2.17)
230
(9.06)
155
(6.10)
62
(2.44)
82
(3.23)
14
(0.55)
55
(2.17)
50
(1.97)
38
(1.50)
8
(0.31)
5
(0.20)
10
(0.39)
M10 × 22
34.6
(76.3)
09AAS76
1/29
95
(3.74)
115
(4.53)
15
(0.59)
55
(2.17)
230
(9.06)
155
(6.10)
62
(2.44)
82
(3.23)
14
(0.55)
55
(2.17)
50
(1.97)
38
(1.50)
8
(0.31)
5
(0.20)
10
(0.39)
M10 ×22
34.6
(76.3)
13AASA6
1/6
75
(2.95)
90
(3.54)
12
(0.47)
40
(1.57)
180
(7.09)
135
(5.31)
45
(1.77)
60
(2.36)
11
(0.43)
35
(1.38)
32
(1.26)
28
(1.10)
7
(0.28)
4
(0.16)
8
(0.31)
M8 × 19
26.6
(58.6)
13AASB6
1/11
95
(3.74)
115
(4.53)
15
(0.59)
55
(2.17)
230
(9.06)
155
(6.10)
62
(2.44)
82
(3.23)
14
(0.55)
55
(2.17)
50
(1.97)
38
(1.50)
8
(0.31)
5
(0.20)
10
(0.39)
M10 ×22
36.6
(80.7)
13AASC6
1/21
95
(3.74)
115
(4.53)
15
(0.59)
55
(2.17)
230
(9.06)
155
(6.10)
62
(2.44)
82
(3.23)
14
(0.55)
55
(2.17)
50
(1.97)
38
(1.50)
8
(0.31)
5
(0.20)
10
(0.39)
M10 × 22
36.6
(80.7)
20AASA6
1/6
95
(3.74)
115
(4.53)
15
(0.59)
55
(2.17)
230
(9.06)
155
(6.10)
62
(2.44)
82
(3.23)
14
(0.55)
55
(2.17)
50
(1.97)
38
(1.50)
8
(0.31)
5
(0.20)
10
(0.39)
M10 × 22
43
(94.8)
20AASB6
1/11
95
(3.74)
115
(4.53)
15
(0.59)
55
(2.17)
230
(9.06)
155
(6.10)
62
(2.44)
82
(3.23)
14
(0.55)
55
(2.17)
50
(1.97)
38
(1.50)
8
(0.31)
5
(0.20)
10
(0.39)
M10 ×22
43
(94.8)
30AASA6
1/6
95
(3.74)
115
(4.53)
15
(0.59)
55
(2.17)
230
(9.06)
155
(6.10)
62
(2.44)
82
(3.23)
14
(0.55)
55
(2.17)
50
(1.97)
38
(1.50)
8
(0.31)
5
(0.20)
10
(0.39)
M10 × 22
47
(104)
30AASB6
1/11
95
(3.74)
115
(4.53)
15
(0.59)
55
(2.17)
230
(9.06)
155
(6.10)
62
(2.44)
82
(3.23)
14
(0.55)
55
(2.17)
50
(1.97)
38
(1.50)
8
(0.31)
5
(0.20)
10
(0.39)
M10 × 22
47
(104)
