4 Inspections
E-17
4
Inspections
Perform inspections and part replacements according to the information
that is provided in this section.
4.1
Daily Inspections
The daily inspection items are given in the following table.
* MP3000-series MP3200/MP3300 Troubleshooting Manual
(Manual No.: SIEP C880725 01)
Inspection Item Description Criteria Correction
Installation
condition
Loose screws
or covers
All screws and covers
must be secure.
Tighten the
screws.
Connection
conditions
Loose termi-
nal screws
Screws must not be
loose.
Tighten the termi-
nal screws.
Connectors
Connectors must not
be loose.
Tighten the lock
screws on the
connectors.
Separation
between
crimped ter-
minals
Suitable gaps must
be maintained.
Correct the gaps.
Indi-
cators
POWER
indicator
Check the
status when
power is ON.
Must be lit.
(Otherwise, there is
an error.)
Refer to the rele-
vant manual.*
To Next Page
