YASKAWA MP2200 Series User Manual

6 Receiving
E-7
6 Receiving
Confirm the model number of each product upon receiving the delivery.
Products Abbrevia-
tion
Model Outline
MP2200
Main Unit
Base Unit MBU-01 JEPMC-BU2200 (-E) Power supply, Mounting base
MBU-02 JEPMC-BU2210 (-E) Power supply, Mounting base
MBU-03 JEPMC-BU2220 (-E) Power supply, Mounting base
CPU Module CPU-01 JAPMC-CP2200 (-E) CPU
CPU-02 JAPMC-CP2210 (-E) CPU, USB port, and CF card slot
CPU-03 JAPMC-CP2220-E CPU, Ethernet, and CF card slot
CPU-04 JAPMC-CP2230-E CPU, Ethernet
Connection Module
between Racks
EXIOIF JAPMC-EX2200 (-E) Connection between racks
MP2300
Main Unit
Basic Module MP2300 JEPMC-MP2300 (-E) Power supply, Mounting base, CPU,
MECHATROLINK-I, MECHATROLINK-II,
8 inputs, 4 outputs
MP2310
Main Unit
Basic Module MP2310 JEPMC-MP2310-E Power supply, Mounting base, CPU,
MECHATROLINK-I, MECHATROLINK-II,
Ethernet communication
MP2300S
Main Unit
Basic Module MP2300S JEPMC-MP2300S-E Power supply, Mounting base, CPU,
MECHATROLINK-I, MECHATROLINK-II,
Ethernet communication
MP2400
Main Unit
Basic Module MP2400 JEPMC-MP2400-E Power supply, Mounting base, CPU,
MECHATROLINK-I, MECHATROLINK-II,
Ethernet communication
Option
Module
Motion Module SVA-01 JAPMC-MC2300 Analog interface
SVB-01 JAPMC-MC2310 (-E) MECHATROLINK-I, -II interface
SVC-01 JAPMC-MC2320-E MECHATROLINK-III
PO-01 JAPMC-PL2310-E Pulse output
Multiple-CPU
Module
MPU-01 JAPMC-CP2700-E Optional Module with CPU + SVC-01 functions
Communications
Module
218IF-01 JAPMC-CM2300 (-E) RS232C/Ethernet communication
218IF-02 JAPMC-CM2302-E
217IF-01 JAPMC-CM2310 (-E) RS232C/RS422 communication
260IF-01 JAPMC-CM2320 (-E) RS232C/DeviceNet communication
261IF-01 JAPMC-CM2330 (-E) RS232C/PROFIBUS communication
262IF-01 JAPMC-CM2303-E FL-net communication
263IF-01 JAPMC-CM2304-E EtherNet/IP communication
264IF-01 JAPMC-CM2305-E EtherCAT communication
265IF-01 JAPMC-CM2390-E CompoNet communication
266IF-01 JAPMC-CM2306-E PROFINET communication
266IF-02 JAPMC-CM2307-E
215AIF-01 JAPMC-CM2360 (-E) RS232C/MPLINK communication
I/O Module LIO-01 JAPMC-IO2300 (-E) 16 inputs, 16 outputs (sink mode output)
1 pulse input
LIO-02 JAPMC-IO2301 (-E) 16 inputs, 16 outputs (source mode output)
1 pulse input
