7 MECHATROLINK-II Commands
35
In the following case, a warning is generated and the command is ignored.
• If not in phase 2 or 3: Command fault (A.95)
Table 5 SEL MON1/2 Selection Range
MON1/2 Item Remarks
0 Nothing selected.
1 Output frequency
According to o1-03.
2 Torque reference (U1-09): 0.1 %
3 Detected speed from PG counter.
4 Frequency reference (U-01)
According to o1-03.
5 INV analog input A2 0.1 %.
6 Main circuit current voltage: 1 V
7 Inverter alarm Refer to the Inverter alarm code list.
8 Inverter warning Refer to the Inverter warning code list.
9 Not used.
A INV analog input A3 0.1 %.
B INV terminal DI input
Bits 0 to 7: Terminals S1 to S8
C INV analog input S1: 0.1 %
D PG counter
E, F Not used. Always 0.
