14
Station-number Setting
A station number is set by both the S1-3 DIP switch and the S2 rotary switch. Station num-
bers from 21 to 3E are valid. Although 20 or 3F can be set as a station number, do not use
these settings because they will be faulty.
S1-3:Set the 10’s digit of the station number.
OFF = 2 (2X)
ON = 3 (3X)
S2: Set the 1’s digit of the station number.
0 = 0 (X0)
1 = 1 (X1)
x x
x x
F = F (XF)
Switch Setting and Station Number
SI-3 S2 Station
Number
S1-3 S2 Station
Number
OFF 0 Fault ON 0 30
OFF 1 21 ON 1 31
OFF 2 22 ON 2 32
OFF 3 23 ON 3 33
OFF 4 24 ON 4 34
OFF 5 25 ON 5 35
OFF 6 26 ON 6 36
OFF 7 27 ON 7 37
OFF 8 28 ON 8 38
OFF 9 29 ON 9 39
OFF A 2A ON A 3A
OFF B 2B ON B 3B
OFF C 2C ON C 3C
OFF D 2D ON D 3D
OFF E 2E ON E 3E
OFF F 2F ON F Fault
