YCF F190SPIII - Page 116

115
English
CYLINDER/PISTON
ITEM
QTY
Thread Dia. (mm)
TORQUE Nm (kgf-m)
Drive chain sprocket mounting bolt
1
8
9,8 (1,0)
ALTERNATOR/TIMING CHAIN TENSIONER
ITEM
QTY
Thread Dia. (mm)
TORQUE Nm (kgf-m)
Flywheel bolt
1
10
41 (4,2)
Timing chain tensioner seal
1
14
23 (2,3)
Adjustment bolt, camshaft tensioner
1
8
16 (1,6)
CRANKCASE/GEARSHIFT LINKAGE
ITEM
QTY
Thread Dia. (mm)
TORQUE Nm (kgf-m)
Gearshift drum bearing set bolt
1
6
12 (1,2)
FRAME/FRAME BODY PANEL/EXHAUST SYSTÈM
ITEM
QTY
Thread Dia. (mm)
TORQUE Nm (kgf-m)
Sidestand adjustment bolt & nut
1
10
voir page 2-10
Muffler hold-down screw
1
8
32 (3,3)
Exhaust pipe protector bolt
3
6
15 (1,5)
Fuel tank hold-down bolt
2
6
12 (1,2)
Exhaust pipe cover bolt
4
5
5,9 (0,6)
