YCF F190SPIII - CLUTCH SYSTEM; Clutch Adjustment

129
English
CLUTCH SYSTEM
When shifting into the next gear the clutch should provide smooth engagement to all the gears easily without
chattering. You will know you need to adjust the clutch when you feel it "slipping"
( A ) Clutch lever
( B ) Locknut
( C ) Adjuster
Clutch Adjustment
1. Check free-play at the clutch lever. If it goes beyond 5mm (0.20 inch), then adjustment is necessary.
2. Loosen the locknut (B).
3. Turn the adjuster (C) at the lever until the free-play is within the specified limits.
4. Tighten the locknut (B).
C
C
A
B
A
A
A
C
A
C
