YCF F190SPIII - Page 118

117
English
ENGINE DISASSEMBLY/ASSEMBLY
ITEM
QTY
Thread Dia. (mm)
TORQUE Nm (kgf-m)
Engine mounting bolt & nut
2
8
31 (3,2)
Drive gear box mounting plate nut
2
6
12 (1,2)
REAR WHEEL/SUSPENSION BRAKE SPECIFICATIONS
ITEM
QTY
Thread Dia. (mm)
TORQUE Nm (kgf-m)
Spoke
32
BC 2,9
2,9 (0,3)
Rear wheel axle bolt & nut
1
15
59 (6,0)
Drive sprocket nut
4
8
32 (3,3)
Rear suspension arm brake nut
1
6
9,8 (1,0)
Swingarm pivot nut
1
10
39 (4,0)
Rear shock absorber bolt & nut
2
10
34 (4,5)
IGNITION SYSTEM SPECIFICATIONS
ITEM
QTY
Thread Dia. (mm)
COUPLE DE
SERRAGE N∙m (kgf)
Ignition coil bolt
1
5
5,9 (0,6)
