Yealink SIP-T20P Quick Installation

Packing List
Assembling the Phone
IP Phone Handset
Handset Cord
Internet
1. Attach the Stand, shown as below:
The phone can also share the network connection with other network devices such as PC. Connect the
phone's PC port and computer's Network Port together using an Ethernet cable, shown as below:
There are two ways for network and power source connections. You can either connect the phone to
the AC Power directly by using the power adapter or to a PoE compliant switch or hub. Your system
administrator will advise you on which one to use.
3. Connect Network and Power
Note: If inline power (PoE) is provided, do not install the AC adapter. Make sure the Ethernet cable and switch/hub are
PoE compliant.
PC
Power Adapter
2. Connect Handset and Headset, shown as below:
Note: Headset is not included, should be purchased separately.
Ethernet Cable
CD Content
Stand attached
On the wall

Yealink SIP-T20P Specifications

General

Keypad number of keys	31
Speakerphone	Yes
Voice codecs	G.711, G.722, G.723.1, G.726
Mounting	Desk/Wall
Handset type	Wired handset
Product type	IP Phone
Product color	Black
Touchscreen	-
Lines quantity	2 lines
Phonebook capacity	1000 entries
Number of VoIP accounts	2
Bluetooth	No
Security algorithms	HTTPS, SSL/TLS
AC adapter input voltage	100 - 240 V
AC adapter output voltage	5 V
Power consumption (typical)	2.6 W
Operating relative humidity (H-H)	10 - 95 %
Compliance industry standards	IEEE 802.3af
Number of handles included	1 pc(s)

Weight and Dimensions

Depth	200 mm
Width	185 mm
Height	90 mm
Weight	770 g
