Yealink SIP-T23G Provisioning Guide

Yealink IP Phones Auto Provisioning Guide
24
The following shows an example of a directory template:
<root_favorite_set>
<item id_name="localdirectory" display_name="Local Directory"
priority="1" enable="1" />
<item id_name="history" display_name="History" priority="2"
enable="0" />
<item id_name="remotedirectory" display_name="Remote Phone Book"
priority="3" enable="0" />
<item id_name="ldap" display_name="LDAP" priority="4" enable="0" />
<item id_name="networkdirectory" display_name="Network Directories"
priority="5" enable="0" />
</root_favorite_set>
## Specify the access URL of the custom directory template.
directory_setting.url =
For example, enter “tftp://192.168.1.100/favorite_setting.xml” in the “directory_setting.url
=” field. During the auto provisioning process, the IP phone connects to the provisioning
server “192.168.1.100”, and downloads the contact file “favorite_setting.xml”.
For more information on the parameter, refer to Description of Configuration Parameters
in CFG Files on page 81.
Search source list in dialing allows the IP phone to search for entries from the desired
lists when the IP phone is in the dialing screen, and then the user can select the desired
entry to dial out quickly. The lists may contain Local Directory, History, Remote Phone
Book, LDAP and Network Directory. You can configure the search source list in dialing
using the supplied super search template (super_search.xml). After setup, place the
super search template to the provisioning server and specify the access URL in the
configuration files.
When editing a super search template, learn the following:
 Do not rename the super search template.
 <root_super_search> indicates the start of a template and </root_super_search>
indicates the end of a template.
 The default display names of directory lists are Local Directory, History, Remote
Phone Book, LDAP and Network Directory.
 When specifying the priority of search results, the valid values are 1, 2, 3, 4 and 5. 1
is the highest priority, 5 is the lowest.
 When enabling or disabling the IP phone to search the desired directory list, the
valid values are 0 and 1. 0 stands for Disabled, 1 stands for Enabled.

Yealink SIP-T23G Specifications

General

Backlight	Yes
Voice codecs	G.711a, G.722.2, G.726, G.729ab, iLBC
Volume control	Digital
Handset type	Wired handset
Product type	IP Phone
Product color	Black, Silver
Display resolution	132 x 64 pixels
Lines quantity	- lines
Phonebook capacity	1000 entries
Number of VoIP accounts	3
Networking standards	IEEE 802.1p, IEEE 802.1Q, IEEE 802.1x, IEEE 802.3af
Ethernet LAN (RJ-45) ports	2
AC adapter input voltage	100 - 240 V
AC adapter output current	0.6 A
AC adapter output voltage	5 V
Power consumption (typical)	1.56 W
Number of handles included	- pc(s)
Operating temperature (T-T)	-10 - 50 °C
Operating relative humidity (H-H)	10 - 95 %

Weight and Dimensions

Depth	188 mm
Width	209 mm
Height	150 mm
