Yealink SIP-T23G Auto Provisioning Guide

Yealink IP Phones Auto Provisioning Guide
20
Product Name
Common CFG File
SIP-T40G
y000000000076.cfg
SIP-T29G
y000000000046.cfg
SIP-T27G
y000000000069.cfg
SIP-T23P/G
y000000000044.cfg
SIP-T21(P) E2
y000000000052.cfg
SIP-T19(P) E2
y000000000053.cfg
CP860
y000000000037.cfg
CP920
y000000000078.cfg
W53P/W60P/CP930W-Base
y000000000077.cfg
W52P/W56P
y000000000025.cfg
Common CFG file contains configuration parameters which apply to phones with the same
model, such as language and volume.
The following figure shows a portion of the common CFG file:
The following table lists guidelines you need to know when editing the common CFG file:
Item
Guidelines
#
The line beginning with “#” is considered to be a comment.
#!version:1.0.0.1
It must be placed in the first line.
Do not edit and delete.
Filename
The filename complies with the requirements that are listed in the
above table.
Line formats and
Rules
Each line must use the following format and adhere to the following
rules:

Yealink SIP-T23G Specifications

General

Backlight	Yes
Voice codecs	G.711a, G.722.2, G.726, G.729ab, iLBC
Volume control	Digital
Handset type	Wired handset
Product type	IP Phone
Product color	Black, Silver
Display resolution	132 x 64 pixels
Lines quantity	- lines
Phonebook capacity	1000 entries
Number of VoIP accounts	3
Networking standards	IEEE 802.1p, IEEE 802.1Q, IEEE 802.1x, IEEE 802.3af
Ethernet LAN (RJ-45) ports	2
AC adapter input voltage	100 - 240 V
AC adapter output current	0.6 A
AC adapter output voltage	5 V
Power consumption (typical)	1.56 W
Number of handles included	- pc(s)
Operating temperature (T-T)	-10 - 50 °C
Operating relative humidity (H-H)	10 - 95 %

Weight and Dimensions

Depth	188 mm
Width	209 mm
Height	150 mm
