Yealink SIP-T40G Recovery Guide

Recovery Mode on Yealink IP phones
8
3. Enter the desired values in the IP Address, Netmask, IP Gateway and HTTP Server fields
respectively.
Note
4. Press to complete the recovery mode.
The IP phone will download and upgrade the firmware from the HTTP server. After upgrading, the IP
phone will initialize successfully and get ready for use.
The LCD screen prompts “Initializing…Please Wait” when upgrading successfully.
Note
5. If the IP phone fails to upgrade, the LCD screen will indicate the failure. The user can repeat the
recovery mode procedures to try again.
For CP920 IP phones, you need to press the volume key ( or ) as the left or right
navigation key.
For SIP-T58A IP phones, you need to press / / as up/down/left/right
navigation key.
You need to press (for SIP-T58A phones), (for SIP-T3 IP phones) to complete the
recovery mode since there is no key.
…. Initializing ….
Please Wait
Welcome
IP Address:
Netmask:
IP Gateway:
HTTP Server:
10. 2. 11.124
255.255.255. 0
10. 2. 11.254
http://10.2.11.10
1

Yealink SIP-T40G Specifications

General

Mounting	Desk/Wall
Handset type	Wired handset
Product type	IP Phone
Product color	Black
Wall mountable	Yes
Wi-Fi	No
Security algorithms	AES, HTTPS, SSL/TLS
Networking standards	IEEE 802.3af
Ethernet LAN interface type	Gigabit Ethernet
Supported network protocols	FTP, TFTP, HTTP, HTTPS
Voice codecs	G.711, G.711a, G.711u, G.722, G.726, G.729ab
RJ-11 ports quantity	1
Ethernet LAN (RJ-45) ports	2
AC adapter input voltage	100 - 240 V
AC adapter output current	0.6 A
AC adapter output voltage	5 V
Power consumption (typical)	1.6 W
Certification	CE, FCC, ISO 9001
Operating temperature (T-T)	-10 - 50 °C
Operating relative humidity (H-H)	10 - 90 %
Volume control	Digital
Display diagonal	2.3 \
Display resolution	132 x 64 pixels
Lines quantity	3 lines
Phonebook capacity	1000 entries
Number of VoIP accounts	3
Number of handles included	1 pc(s)

Weight and Dimensions

Depth	175 mm
Width	212 mm
Height	54 mm
