Item Description
1 LCD screen
Shows information about calls, messages, softkeys, time, date, and other
relevant data:
• Default account
• Call information (caller ID, call duration)
• Icons (for example, )
• Missed call text or second incoming caller information
• Prompt text (for example, “Saving config file!”)
• Time and date
2
Power
indicator LED
Indicates call status, message status, and phone system status:
• Incoming call: rapid flashing
• Received voicemail or text message: slow flashing
3 Line keys Use these keys to activate up to three accounts and assign various features.
4
Headset key Toggles and indicates headset mode.
Mute key Toggles and indicates the mute feature.
5
Message key Accesses voice messages.
Hold key Places a call on hold or resumes a held call.
Redial key Redials a previously-dialed number.
Transfer key Transfers a call to another party.
6
Speakerphone
key
Toggles and indicates the hands-free (speakerphone) mode.
The LED on the key turns green when speakerphone mode is activated.
7 Volume key Adjusts the volume of the handset, headset, speaker, ringer, or media.
8 Keypad Provides digits, letters, and special characters in context-sensitive applications.
9
Scroll through the displayed information.
Confirms actions or answers incoming calls.
Cancels actions or rejects incoming calls.
10 Softkeys Label automatically to identify their context-sensitive features.
11 Speaker Provides hands-free (speakerphone) audio output.
12 Reversible tab
Secures the handset in the handset cradle when the IP phone is mounted
vertically. For more information on adjusting the reversible tab, refer to the
Yealink Wall Mount Quick Installation Guide for Yealink IP Phones.
13 Hookswitch
• When the handset is picked up from the handset cradle, the hookswitch
bounces and the phone connects to the line.
• When the handset is placed in the handset cradle, the phone disconnects
from the line.
5
Quick User Guide—Yealink SIP-T46S
wwww.vantact.com 2021
www.vantact.com - 2021 v1.0.0-eng
