Yealink SIP-T53W Administrator's Guide

Phone Provisioning
100
[T42S]features.dnd.enable = 0
Custom configuration file:
Linekey.cfg
linekey.2.type=13
linekey.2.line=1
linekey.2.value = 4603
linekey.2.label=Bill
MAC-Oriented configuration files:
001565b09d886.cfg
account.1.enable = 1
account.1.label = Bill
account.1.display_name = 1023
account.1.auth_name = 1023
account.1.user_name = 1023
account.1.password = 1023
account.1.sip_server.1.address = 10.2.1.199
account.1.sip_server.1.port = 5060
3.
Place the configuration files to the home directory of the provisioning server. For example, D:\TFTP Provision.
4.
Specify the configuration files paths in the boot file as desired. For example,
y000000000000.boot
include:config<tftp:/10.2.5.193/CustomSettings.cfg>
[T46S,T48S]include:config “tftp:/10.2.5.193/Linekey.cfg”
001565b09d886.boot
include:config<tftp:/10.2.5.193/Linekey.cfg>
include:config<tftp:/10.2.5.193/001565b09d886.cfg>
5.
Place the boot files to the home directory of the provisioning server. For example, D:\TFTP Provision.
6.
Reboot the phones to trigger auto provisioning.
For the phone with MAC 001565b09d886, it will download the 001565b09d886.boot file, and then download
Linekey.cfg and 001565b09d886.cfg files referenced in the 001565b09d886.boot file in sequence from the pro-
visioning server.
For the phones except for MAC-specific phone, they will request to download the y000000000000.boot file, and
then request to download the referenced files. The phone-specific configuration file Linekey.cfg only applies to
T46S and T48S phones. The only difference is that T46S and T48S phones will download both the two files since
the exclude mode is disabled by default. The other phones will only download the CustomSettings.cfg file.
For the parameter settings in the CustomSettings.cfg file, the phone-specific parameters will only take effect on the
specific phone models.
The following shows the provisioning flowchart for different phone models with phone-specific settings.

Yealink SIP-T53W Specifications

General

Mounting	Desk/Wall
Handset type	Wired handset
Product type	IP mobile phone
Product color	Gray
Keypad illumination	Yes
Wi-Fi standards	802.11a, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	4.2
Security algorithms	AES, HTTPS, SIPS
Networking standards	IEEE 802.1p, IEEE 802.1x, IEEE 802.3af
Ethernet LAN interface type	Gigabit Ethernet
Supported network protocols	FTP/TFTP/HTTP/HTTPS
Dual-Tone Multi-Frequency (DTMF) modes	In-band, Out-of band, SIP info
USB 2.0 ports quantity	1
Ethernet LAN (RJ-45) ports	2
Lines quantity	8 lines
Phonebook capacity	1000 entries
Number of VoIP accounts	12
AC adapter input voltage	100 - 240 V
AC adapter output current	1.2 A
AC adapter output voltage	5 V
Power consumption (typical)	2.3 W
Volume control	Buttons
Number of programmable keys	8
Storage temperature (T-T)	-30 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 95 %
Display diagonal	3.7 \
Display resolution	360 x 160 pixels
Cables included	LAN (RJ-45)
Number of handles included	1 pc(s)
Number of DECT wireless handsets	4
Voice codecs	G.722, G.723.1, G.726, G.729A, G.729B, OPUS, iLBC

Weight and Dimensions

Depth	210.6 mm
Width	212 mm
Height	174.5 mm
