Yealink SIP-T53W Administrator's Guide

Administrator’s Guide for SIP-T2 Series/T4 Series/T5 Series/CP920 IP Phones
465
Variable Value Description
$mac The MAC address of the IP phone.
$ip The IP address of the IP phone.
$model The IP phone model.
$firmware The firmware version of the IP phone.
$active_url
The SIP URI of the current account when the IP phone places a call, receives an incoming
call or establishes a call.
$active_user
The user part of the SIP URI for the current account when the IP phone places a call,
receives an incoming call or establishes a call.
$active_host
The host part of the SIP URI for the current account when the IP phone places a call,
receives an incoming call or establishes a call.
$local
The SIP URI of the caller when the IP phone places a call.
The SIP URI of the callee when the IP phone receives an incoming call.
$remote
The SIP URI of the callee when the IP phone places a call.
The SIP URI of the caller when the IP phone receives an incoming call.
$display_local
The display name of the caller when the IP phone places a call.
The display name of the callee when the IP phone receives an incoming call.
$display_remote
The display name of the callee when the IP phone places a call.
The display name of the caller when the IP phone receives an incoming call.
$call_id The call-id of the active call.
$callerID The display name of the caller when the IP phone receives an incoming call.
$calledNumber The phone number of the callee when the IP phone places a call.
$exp_number The number of connected expansion modules.
$ehs_number The number of connected EHS.
$udisk_number The number of connected USB flash drives.
$usbheadset_number The number of connected USB headset devices.
$wifi_number The number of connected Wi-Fi dongles.
$bluetooth_number The number of connected Bluetooth dongles.
$vpn_ip The phone IP address assigned by the VPN server.
$cfg_all
The CFG configuration file contains all current configurations of the IP phone.
Note: The valid URI is: http://<serverIPAddress>/<filename>/?variable name=$variable
value.
Example:
http://10.82.21.10/Upload/?Cfg=$cfg_all
$cfg_local
The CFG configuration file contains all non-static parameters made via the phone user
interface and web user interface.
Note: It works only if “static.auto_provision.custom.protect” is set to 1 (Enabled). The valid
URI is: http://<serverIPAddress>/<filename>/?variable name=$variable value.
Example:

Yealink SIP-T53W Specifications

General

Mounting	Desk/Wall
Handset type	Wired handset
Product type	IP mobile phone
Product color	Gray
Keypad illumination	Yes
Wi-Fi standards	802.11a, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	4.2
Security algorithms	AES, HTTPS, SIPS
Networking standards	IEEE 802.1p, IEEE 802.1x, IEEE 802.3af
Ethernet LAN interface type	Gigabit Ethernet
Supported network protocols	FTP/TFTP/HTTP/HTTPS
Dual-Tone Multi-Frequency (DTMF) modes	In-band, Out-of band, SIP info
USB 2.0 ports quantity	1
Ethernet LAN (RJ-45) ports	2
Lines quantity	8 lines
Phonebook capacity	1000 entries
Number of VoIP accounts	12
AC adapter input voltage	100 - 240 V
AC adapter output current	1.2 A
AC adapter output voltage	5 V
Power consumption (typical)	2.3 W
Volume control	Buttons
Number of programmable keys	8
Storage temperature (T-T)	-30 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 95 %
Display diagonal	3.7 \
Display resolution	360 x 160 pixels
Cables included	LAN (RJ-45)
Number of handles included	1 pc(s)
Number of DECT wireless handsets	4
Voice codecs	G.722, G.723.1, G.726, G.729A, G.729B, OPUS, iLBC

Weight and Dimensions

Depth	210.6 mm
Width	212 mm
Height	174.5 mm
