Yealink SIP-T53W Administrator's Guide

Administrator’s Guide for SIP-T2 Series/T4 Series/T5 Series/CP920 IP Phones
479
Variable Value Phone Action
A and D are in a call, the call is active;
B and D are in a call, the call is placed on hold;
C and D are in a call, the call is placed on hold;
callid_A: 32775
callid_B: 32776
Example:
http://10.10.20.10/servlet?key=ATrans=32775@32776
It means A and B join together and then disconnect with D. But the
call between C and D is still in a hold state.
Note: To get the call-id of the active call, configure the action URL:
http(s)://<serverIPAddress>/help.xml?CallId=$call_id. For more
information, refer to Action URL.
BTrans=xxx Perform a blind transfer to xxx.
phonecfg=get[&accounts=x][&dnd=x][&fw=x]
Get firmware version, registration, DND or forward configuration
information.
The valid value of “x” is 0 or 1, 0 means you do not need to get con-
figuration information. 1 means you want to get configuration inform-
ation.
Note: The valid URI is: http(s)://<phoneIPAddress > /ser-
vlet?phonecfg=get[&accounts=x][&dnd=x][&fw=x].
Example:
http://10.3.20.10/servlet?phonecfg=get[&accounts=1][&dnd=0]
[&fw=1]
phonecfg=set[&configuration para-
meter=value]
Set the valid value for the specified configuration parameter.
Note: The valid URI is: http(s)://<-
phoneIPAddress>/servlet?phonecfg=set[&configuration para-
meter=value]...[&configuration parameter=value]. It can contain up to
10 configuration parameters.
Example:
http://10.3.20.10/servlet?phone cfg=set[&account.1.enable=1][&fea-
tures.dnd.enable=1]
phonecfg=get[&configuration parameter]
Get the specified configuration information.
Note: The valid URI is: http(s)://<-
phoneIPAddress>/servlet?phonecfg=get[&configuration parameter]...
[&configuration parameter]. It can contain up to 10 configuration para-
meters.
Example:
http://10.3.20.10/servlet?phonecfg= get[&account.1.enable][&fea-
tures.dnd.enable]
CallWaitingOn Activate the call waiting feature.
CallWaitingOff Deactivate the call waiting feature.
AlwaysFwdOn/BusyFwdOn/NoAn- Activate an always/busy/no answer forward feature to xxx for the IP

Yealink SIP-T53W Specifications

General

Mounting	Desk/Wall
Handset type	Wired handset
Product type	IP mobile phone
Product color	Gray
Keypad illumination	Yes
Wi-Fi standards	802.11a, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	4.2
Security algorithms	AES, HTTPS, SIPS
Networking standards	IEEE 802.1p, IEEE 802.1x, IEEE 802.3af
Ethernet LAN interface type	Gigabit Ethernet
Supported network protocols	FTP/TFTP/HTTP/HTTPS
Dual-Tone Multi-Frequency (DTMF) modes	In-band, Out-of band, SIP info
USB 2.0 ports quantity	1
Ethernet LAN (RJ-45) ports	2
Lines quantity	8 lines
Phonebook capacity	1000 entries
Number of VoIP accounts	12
AC adapter input voltage	100 - 240 V
AC adapter output current	1.2 A
AC adapter output voltage	5 V
Power consumption (typical)	2.3 W
Volume control	Buttons
Number of programmable keys	8
Storage temperature (T-T)	-30 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 95 %
Display diagonal	3.7 \
Display resolution	360 x 160 pixels
Cables included	LAN (RJ-45)
Number of handles included	1 pc(s)
Number of DECT wireless handsets	4
Voice codecs	G.722, G.723.1, G.726, G.729A, G.729B, OPUS, iLBC

Weight and Dimensions

Depth	210.6 mm
Width	212 mm
Height	174.5 mm
