2. Insert the tabs on the wall mount bracket into the
slots on the back of IP phone. And then slide the wall
mount bracket to right.
For a SIP-T48S/T48G/T29G/T27P/T27G IP phone:
PUSH
For SIP-T46S/T46G IP phones:
Yealink provides the wall mount drilling template for
each IP phone model, which locates and marks the
position for mounting the screws (not provided) on the
wall, as shown below:
Mounting the Wall Mount Bracket
For a SIP-T58V/T58A/T56A IP phone:
PUSH
PC
Internet
DC5V
PC
Internet
DC5V
For a SIP-T58V/T58A/T56A IP phone:
www.yealink.com
Wall Mount Quick Installation Guide
For a SIP-T48S/T48G IP phone:
118.00mm
118.00mm
Screw position
Max:8mm
(0.315”)
Min:6.5mm
(0.256”)
x 4
Max:4.5mm
(0.177”)
Max:8mm
(0.315”)
Min:6.5mm
(0.256”)
Screw position
x 3
147.90mm
81.76mm
70.11mm

Other manuals for Yealink SIP-T58A

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Yealink SIP-T58A and is the answer not in the manual?

Yealink SIP-T58A Specifications

General IconGeneral
Touchscreen typeCapacitive
Display resolution1024 x 600 pixels
Operating system version5.1.1
Operating system installedAndroid
Dual-Tone Multi-Frequency (DTMF) modesIn-band, Out-of band, SIP info
MountingDesk/Wall
Handset typeWired handset
Product typeIP Phone
Product colorBlack
BluetoothNo
Security algorithmsSRTP
Networking standardsIEEE 802.1x
Ethernet LAN interface typeGigabit Ethernet
Supported network protocolsFTP/TFTP/HTTP/HTTPS, IPv4/IPv6, UDP/TCP/DNS-SRV
USB 2.0 ports quantity2
Voice codecsG.711Mu, G.711a, G.722, G.722.1, G.722.1C, G.723, G.726, G.729ab, iLBC
Lines quantity- lines
Phonebook capacity1000 entries
Number of VoIP accounts16
Front camera resolution (numeric)2 MP
Base station keys27
AC adapter input voltage100 - 240 V
AC adapter output current2 A
Power consumption (typical)1.9 W
Operating temperature (T-T)-10 - 40 °C
Operating relative humidity (H-H)10 - 95 %
Cables includedLAN (RJ-45)
Number of handles included1 pc(s)
Weight and Dimensions IconWeight and Dimensions
Depth220 mm
Width259.4 mm
Height239 mm
Package depth293 mm
Package width324 mm
Package height128 mm
