Yealink UVC40 User Manual

2
Wall Mounting
Use the bracket to mount your endpoint on a wall. The mounting height affects your
camera view. The recommended height is 1.1m above the ground.
Placing UVC40
Mount the UVC40 below the TV when
the mounting height of the TV is higher than
120cm.
Mount the UVC40 above the TV when
the mounting height of the TV is lower
than 120cm.
Step1：Assemble the mounting bracket
Mount on a Wall
TV
10cm
TV
H>120cm
H<120cm

Yealink UVC40 Specifications

General

Megapixel	20 MP
Camera type	Single camera
Sensor type	CMOS
Image sensor size	- \
Optical sensor size	1/1 \
Field of view (FOV) angle	133 °
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 10.15.3 Catalina
Windows operating systems supported	Windows 10, Windows 7
Built-in microphone	Yes
HD type	-
Maximum frame rate	60 fps
Maximum video resolution	- pixels
Product color	Black
USB cable length	7 m
Product type	Personal video conferencing system
Certification	CE
Number of cameras	1
Number of persons	- person(s)
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
AC input voltage	100 - 240 V
DC output current	0.7 A
DC output voltage	48 V
Power source type	DC
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 95 %
Number of microphones	8
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	68 mm
Width	600 mm
Height	82 mm
Weight	2560 g
