Yealink W79P Quick Reference Guide

Power over Ethernet
+ Connect the Ethernet cable between the Internet port on the base station and an available port on the in-line power
switch/hub.
IEEE 802.3af compliant PoE Switch
NOTE: If in-line power is provided, you don’t need to connect the AC adapter.
Make sure the switch is PoE compliant.
IMPORTANT! Do not remove the power and network to the base station while it is updating firmware and
configurations.
Yealink W79 DECT Phone
Quick Reference Guide
www.momentumtelecom.com/support | 888.538.3960
4

Yealink W79P Specifications

General

Mounting	Desk/Wall
Device lock	Yes
Handset type	Wireless handset
Product type	IP mobile phone
Product color	Black
Frequency band	1.9 GHz
Lines quantity	20 lines
Phonebook capacity	1000 entries
Number of VoIP accounts	-
Networking standards	IEEE 802.3af
Ethernet LAN data rates	10, 100 Mbit/s
Keypad number of keys	25
Number of function keys	6
Display diagonal	1.8 \
Display resolution	128 x 160 pixels
Maximum indoor range	50 m
Maximum outdoor range	300 m
Ethernet LAN (RJ-45) ports	1
Battery voltage	3.7 V
Battery capacity	1460 mAh
AC adapter input voltage	100 - 240 V
Storage temperature (T-T)	-30 - 70 °C
Operating temperature (T-T)	-10 - 50 °C
Operating relative humidity (H-H)	10 - 95 %
Number of handles included	- pc(s)
Harmonized System (HS) code	85171800

Weight and Dimensions

Package depth	182 mm
Package width	205 mm
Package height	95 mm
Package weight	9096 g
Base dimensions	130 x 100 x 25.1 mm
Handset dimensions (WxDxH)	157 x 51 x 24 mm
