Yellowtec PUC2 Briefing Book

22
PUC2 Line
PUC2 Line Rear Panel
Analog Input*
The balanced analog line
inputs are located on the
rear panel of PUC2 Line.
When an AES-3 signal is
present on the front
panel, the analog input
will be muted.
Analog Output*
The balanced analog line
output operates in parallel
to the AES-3 output and
is always on. Make sure
that the correct levels are
selected for the digital
headroom. See page 11.
*Due to dierent standards of reference levels, PUC2 Line
comes either leveled for international or for German standards.
Input + Output @FS Headroom Rated Input + Output
+ 15 dBU - 9 dB FS + 6 dBU
+ 18 dBU - 14 dB FS + 4 dBU
German Reference Levels
Int‘l ReferenceLevel
