Yeti SB100 User Manual

3 %.
3 &.
ITEM# PART # DESCRIPTION QTY
1 N/A SB100 FRONT TRIANGLE ASSEMBLY
1.1 N/A SB100 FRONT TRIANGLE 1
1.2 300070006 ICE AXE HEAD BADGE 1
1.3 400100173 SB100 DT PROTECTOR 1
1.4 300060072 YETI SEAT CLAMP STANDARD 1
1.5 300030010 BOLT-CAP H20 (M5 X 0.8 X 16MM) 2
1.6 300030148 WASHER, 5.1X8.9X1MM 2
2
N/A
SB100 SWING ARM ASSEMBLY
1
2.1
N/A
SB100 SWINGARM
1
2.2
400100174
SB100 CS/SS PROTECTOR
2.3
400100175
SB100 CS LOWER PROTECTOR 1
2.4 300020001 BEARING, 17X30X7, 6903-2RS MAX 2
2.5
300020052 BEARING, 15X28X7/10 LLU MAX-E 2
2.6
200020311 LOCKRING, SS PIVOT 2
2.7 300060073 12X148 HANGER STD KIT GEN3 1
2.7.1 300060074 12X148 HANGER STANDARD GEN3 1
2.7.2 300060075 12X148 HANGER CAP GEN3 1
3
00787
FOX LINEAR BEARING 74.0MM ASSEMBLY
4 N/A SHOCK ASSEMBLY SB100
4.1 N/A FOX FLOAT DPS 190X37.5MM 1
4.2 N.A FOX MOUNT KIT 25.0MM 1
5.1
N/A SB100 LINK ASSEMBLY
1
5
300040499
SB100 LINK - ALLOY
5.2
300020052
BEARING, 15X28X7/10 LLU MAX-E
2
N/A
SB100 ASSEMBLY PARTS
6.1
400100194 FENDER, SWITCH INFINITY INT CLIP 1
EXPLODED VIEW PARTS LIST
ITEM# PART # DESCRIPTION QTY
200020313
PIVOT HARDWARE, MAIN, 17MM PYRAMID HEAD
2
6.5
200020314
GREASE ZERK, FOX
2
6.6
300030294 BOLT, SS PIVOT, 15MM
2
6.7 300030292 STUD, LINK BEARING, FEMALE 15MM
1
6.8 300030293 BOLT, LINK PIVOT, MALE 15MM
1
6.9 300030156 SHOULDER BOLT, M6X1 FH, TI
4
6.10
300030301 BOLT, TI FEMALE 8.0 X 11.75MM
4
6.11
300030295 SHOCK BOLT, 8MM, FLAT HEAD
2
N/A
100425006 AXLE, YETI BOLT ON, 12X148MM
1
N/A 400100177 FRAME PROTECTOR KIT, SB100 (GLOSS)
1
N/A 400100171 FRAME PROTECTOR KIT, SB100 (MATTE)
1
N/A 300070010 OWNERS MANUAL
1
6
6.4
1
1

Yeti SB100 Specifications

General

Suspension	Full Suspension
Category	Mountain Bike
Frame Material	Carbon
Wheel Size	29 inches
Travel	100mm
