Yeti SB5 - Frame Assembly: Pivot Axle Installation; Main Pivot and Upper Link Axle Steps

Grease the upper link pivot pin (300040484) and
push it through the swing arm and link from the
non-drive side. NOTE: You may want to use a
guide pin (200020118) to assist in aligning the
sleeve in the link.
26. 27.
Thread the main pivot axle into the main pivot
axle nut using a 10mm allen wrench. Lightly
tighten by hand and nish with a torque wrench
*Torque to 3.5 Nm
Place the spacing washers (300020049) on the
bearings on the upper bearings of the link. The
light lm of grease will hold them in place.
Slide the link into the swing arm, aligning the
upper link pivot. You may need to rotate the
swing arm or move the Innity Link up or down to
get the pivot to align.
13. 14.
15.
16.
ASSEMBLY
With the main pivot axle in place, grab the main
pivot axle nut (300030285) and install it in the
keyed recess on the drive side of the swing arm.
ASSEMBLY
17.
With the upper link pivot axle in place, grab the
upper link pivot axle nut (300030286) and push
it into the keyed recess on the drive-side of the
swing arm. Using a 5mm allen wrench, lightly
tighten the axle. Finish with a torque wrench.
*Torque to 3 Nm
18.
Returning to the main pivot. Grease the threads
and collet wedge of the main pivot collet wedge
bolt (300040454) and thread it into the main pivot
collet axle.
19.
Tighten rmly by hand and nish with a torque
wrench.
*Torque to 14 Nm
20.
