BOYUTLAR – DIMENSIONS – РАЗМЕРЫ
6
90º DERECEDE
Min. 400 mm
Max. 4000 mm
400 mm
º DERECEDE
90º DERECEDE
Min. 400 mm
Max. 4000 mm
Min. 400 + (2 x H) mm
Max. 4000 + (2 x H) mm
º DERECEDE
RESİM & FIGURE & РИСУНОК – 1
Min. 580 mm
Max. 4000 mm
