44
TEMPERATURE TEST
This test will allow you to verify that your pellet cooker is functioning normally. When running this test,
it is strongly suggested that you use BBQr’s Delight brand pellets, if available. For proper results,
remove old pellets from the hopper and use fresh pellets.
This test will take 2 hours. Please make sure the ACS controller is connected to the Fireboard app via
Wi-Fi prior to starting the test. External temperature probes MUST be located on the bottom grate
EXACTLY at the locations shown in the diagram below.
The tip of Probe 1 should be precisely 11 inches from the left wall of the grill, the tip of probe 2 should
be 22 inches from the left wall of the grill, and the variable displacement damper should be pulled
outward to the right. (See diagram below)
RECOMMENDED PROCEDURE FOR THE
ACS TEMPERATURE TEST
