YOKOGAWA 2013 14 User Manual

— 9 —
IM 2013-01
(13種測定範囲 13 range)
形名
Model
2013
2014
コード
Code
01
02 *
03
04
05 *
06
07
08
09
20/100 mA
50/250 mA
100/500 mA
0.2/1 A
0.5/2.5 A
1/5 A
2/10 A
5/25 A
10/50 A
0.3/0.2 VA
0.5/0.5 VA
0.5/0.5 VA
0.4/0.4 VA
0.5/0.5 VA
0.6/0.6 VA
0.7/0.7 VA
1/1 VA
1.2/1.8 VA
00
30/75/150/300/750 V
0.15/0.3/0.75/1.5/3/7.5/15/30 A
電圧測定 Voltage measuring range: 4.5 VA
電流測定 Current measuring range:
7.5 A and below 0.7 VA
15 A 0.9 VA
30 A 2 VA
10
11
12
13
14
20/50/100/200 mA
0.1/0.2/0.5/1 A
0.5/1/2/5 A
2/5/10/20 A
10/20/50/100 A
0.4/0.3/0.2/0.3 VA
0.2/0.3/0.4/0.5 VA
0.7/0.6/0.5/0.3 VA
0.5/0.3/0.6/0.9 VA
0.6/0.9/1.7/2.4 VA
15
16
17
18
19
15/30 V
30/75 V
75/150 V
150/300 V
300/750 V
3.8 VA
0.5/1/2/5 A 400 Hz用
2/5/10/20 A 400 Hz用
10/20/50/100 A 400 Hz用
75/100 V 400 Hz用
150/300 V 400 Hz用
2013 20 * 計器用変流器外付用(5 A)
For use with an external CT (5 A)
0.22 VA
2013 21 *
計器用変圧器外付用(150 V)
For use with an external VT (150 V)
3.8 VA
2013 26 *
2013 27 *
3.75 VA
2013 23 *
2013 24 *
2013 25 *
1.2 VA
2017
30/75/150/300 V30 1 mA
2013 22 *
500 A (500AT) 変流器2244と組合せ使用，with 2244
定格（最大目盛値）
Rating (Range, Maximum scale value)
概略消費VA
Approx. VA Loss
* 受注停止製品
* Discontinued product
