YOKOGAWA 2013 14 User Manual

— 8 —
IM 2013-01
仕 様
動作原理： 2013, 2014 可動鉄片形
2017 整流形
使用温湿度範囲： 0 〜 40℃，25 〜 80％ RH
保存温湿度範囲： − 10 〜 +50℃，25 〜 80％ RH
定格周波数：
2013 01, 2013 03, 2013 04, 2013 06 ～ 2013 19, 2014, 2017
50/60 Hz
2013 02*, 2013 05*, 2013 20* ～ 2013 22*
50/60 Hz
2013 23* ～ 2013 27*
400 Hz
周波数特性： 2017 45 Hz 〜 10 kHz
指針振れ角： 約 85°
目盛長： 約 135 mm
絶縁試験： 電気回路と外箱間 DC 500V にて 10 MΩ 以上
電圧試験： 電気回路と外箱間
2013, 2014 3000 VAC，5 秒間
2017 2000 VAC，5 秒間
質量： 2013, 2017 約 1.7 kg
2014 約 4.2 kg
アクセサリ（別売）：
2013, 2017 用携帯用かばん 2291 01
2014 用携帯用かばん 2292 01
* 受注停止製品
SPECIFICATIONS
Operating Principle: 2013 and 2014 Moving-iron types
2017 Rectier type
Operating Temperature and Humidity Range:
0 to 40°C, 25 to 80% RH
Storage Temperature and Humidity Range:
–10 to 50°C, 25 to 80% RH
Rated Frequency:
2013 01, 2013 03, 2013 04, 2013 06 to 2013 19, 2014, 2017
50/60 Hz
2013 02*, 2013 05*, 2013 20* to 2013 22*
50/60 Hz
2013 23* to 2013 27*
400 Hz
Rated Accuracy: 2017 45 Hz to 10 kHz
Deection Angle: Approx. 85°
Scale Length: Approx. 135 mm
Insulation Test: Between electrical circuit and case
DC 500 V / More than 10 MΩ
Voltage Test: Between measuring circuit and case
2013 and 2014 3000 VAC, for 5 seconds
2017 2000 VAC, for 5 seconds
Weight: 2013 and 2017 approx. 1.7 kg
2014 approx. 4.2 kg
Optional Accessories: Carrying case model 2291 01 for 2013 and 2017
Carrying case model 2292 01 for 2014
*Discontinued product
