YOKOGAWA Centum V User Manual

Appendix 4. Functions Related to Upgrade
App.4-5
TI 33K01B10-50E
Table Functions Related to Upgrade Before R5.03.00 (5/7)
Item Function
CENTUM V or
CENTUM-XL
CENTUM VP Measures
BSETU
compatible
mode
Batch alarm
when batch end
is not complete.
7BS
Batch end: ALRM=HI
Pre-batch: ALRM=LO
BSETU
Batch end: ALRM=END
Pre-batch: ALRM=PRE
BSETU-2/3
Batch end:
BSTS=NCNT or END
Pre-batch:
BSTS=ERLY or PBCH
Specifying[CENTUMV/
CENTUM-XL Compatible] or
[XLcompatibleCENTUM-XL
Compatible ] in the function
block detail builder allows
the transmission of a batch
end alarm when the batch
ends even if the batch end
conditions(SUM≥ BSET-
LPV)arenotsatised.
Pre-batch alarm
when the batch
ends.
After the pre-batch
transmission, the pre-
batch returns at the time
of pre-batch end.
Pre-batch does not
return at the time of pre-
batch end, but, it returns
simultaneously at the time
of batch end when the
next batch starts.
Specifying[CENTUMV/
CENTUM-XL Compatible]
in the function block detail
builder allows the pre-batch
alarm return when the batch
ends.
Handling MV
values when
transferring from
MAN to AUT
mode
MV-value handling when transferring to MAN and
then back to AUT differs between CENTUM-XL or
earlier systems and CS or later systems.
Specifying[CENTUMV/
CENTUM-XL Compatible] or
[XLcompatibleCENTUM-XL
Compatible ] in the function
block detail builder allows
the change of MV values
when transferring from MAN
to AUT mode.
Acceptance of
batch end during
EMST
– CS can specify whether or
not accepting batch end
during EMST, whereas CS
3000 or later systems can
specifyspecicforms.
Specifying “Not accepted”
in[AcceptBatch-Endduring
EMST] in the FCS property
allowsspecicationofthe
presence or absence of
accepting batch end during
EMST.
Way to restart
batch operation
The ways to restart batch operations differ between
CENTUM-XL or earlier systems and CENTUM CS or
a later system.
Specifying[CENTUMV/
CENTUM-XL Compatible] or
[CENTUM-XLCompatible]
in the function block detail
builder, or specifying Yes
inthe[StartfromMLvalue
at the time of restart] menu
allows starting with ML
values when restarting batch
operation.
Way to batch
start in cascade
connections
Thewaystobatchstartwhen[Batchstartin
BSETU-2/3]and[CASsetinfunctionblock
for destination cascade connections] are set
simultaneously in cascade connections differ between
CENTUM-XL or earlier systems and CENTUM CS or
later systems.
Specifying[CENTUMV/
CENTUM-XL Compatible or
[CENTUM-XLCompatible]
in the function block detail
builder, or specifying Yes
inthe[StartfromMLvalue
at the time of restart] menu
allows starting with ML
values when starting batch
processingwhen[Batch
start in BSETU-2/3] and
[CASsetinfunctionblock
for destination cascade
connections] are set
simultaneously in cascade
connections.
Sending of pre-
batch alarms
during EMST
The method of sending pre-batch alarms during
EMST differs between CENTUM-XL or earlier
systems and CENTUM CS or later systems.
Specifying[CENTUM-XL
Compatible] in the function
block detail builder stops
pre-batch alarms from being
transmitted during EMST.
Mar. 27, 2015-00
