YOKOGAWA DX1000 User Manual

16
IM 04L41B01-18E
Specifications
The following table shows the basic specifications of theEtherNet/IPserver function of
the DX.
Specifications Description
Implementation
level
Level2(Message
Server+I/OServer)
Maximum
number of
connections
20 connections (10 sessions)
*1*2
Ports used 44818/tcp, 44818/udp, 2222/udp
*3
Supported
protocols
EIP/PCCC,EIP/native
*4
Messaging Explicit(UCMM,Class3)+I/O(Class1)
Object Assembly,PCCC,Data
Table
*5
Authentication FileNo.10591(Sep4,2007)
*1 A"session,"aframeworkofconnectionmanagementintheencapsulationprotocollayer
ofEtherNet/IP,providessimilarfunctionsasaTCPconnectiontocarryoutmessage
communications.
*2 Although
multipleconnections
canbemadeinonesession,thetotalnumberofconnections
cannot exceed the maximum number of connections.
*3 44818/tcpisusedmainlyforExplicitmessages,2222/udpforI/Omessages,and44818/udp
forcommunicationsofresponsetoRSWhoofRSLinx.
*4 CSP/PCCC(AllenBradley
Ethernet)isnotsupported.
*5 Thedescriptionof
commonobjectisomitted.
