YOKOGAWA DY040 User Manual

9-39
IM 01F06A00-01E
9. GENERAL DESCRIPTION
■ Flameproof Packing Adapter (Option code /G11,/G12)
T1
T2
L
18
G
F
D
C
16.5
*Packing
(Choose from the table below
depend on cable outside diameter)
Unit:mm
Adapter body (M. Screw)
Packing case
Hexagon socket set screw
O-Ring
Packing *
O-Ring
O-Ring
Washer
Union nut
Packing gland
Clamp ring
Clamp nut
O-Ring
Hexagon socket set screw
B.coupling
Cable (user’s scope)
T1
G 1/2 G 1/2
35
39
20.0 0.26
T2 C F GD
94.5
L
8 to 10
10 to 12
10.0
12.0
16 8-10
16 10-12
Size
Identification
mark
Packing dimensions
Weight
(kg)
Cable outer diameter
Fig50
