IM 34M06P15-03E 2nd Edition: Jan. 31, 2012-00

2.5 Response Error Code

This section describes the response error codes.

z If Error Response is Returned

This module returns a response as shown below if there is a mismatch in the PDU

during a request or an error during processing.

F020501.VSD

(PDU at Faulty Completion)

Function Code

Data

1-byte

Error Code

1-byte

Figure 2.5.1 PDU at Faulty Completion

The request function code +$80 value is inserted in the function code (XX).

z Response Error Code

Table 2.5.1 Response Error Code

Error Code Meaning Cause

$01 Function Code Error There is no function code.

$02 Address Error Out-of-range address was specified.

$03 Amount Error Out-of-range amount was specified.

$04 Processing Error Write protect is specified.

$0A CPU Number Error Unit ID that is not from 1 to 4 was specified.

$0B Timeout CPU specified by the unit ID does not exist.
