2-14
IM 34M06P15-03E 2nd Edition: Jan. 31, 2012-00
Settings Specified as Necessary
Settings specified as necessary for using the Modbus/TCP slave function via Ethernet
are as shown below.
Table 2.8.3 Settings Specified as Necessary (Modbus/TCP Slave Function via Ethernet)
Setting Name Setting Type Reference for Details
*1
Network Filter Settings CPU Properties A9.5.8 Network Filter Setup
CPU Operation
Restriction
Operation Protection
Settings
A.6.22.8 CPU Operation Restriction
*1: Refer to items of "Sequence CPU Instruction Manual - Functions (for F3SP71-4N/4S, F3SP76-7N/7S)"
(IM 34M06P15-01E).
z Network Filter Settings
This setting restricts the IP addresses allowed to access this module. The initial value
permits all IP addresses to access this module. This setting is referenced from all
functions that correspond to higher-level link service functions via Ethernet, such as
remote programming service and FTP server.
z CPU Operation Restriction
Use this setting if you want to protect higher-level link services.
CPU operation restriction can be used to protect operating mode switching, log
acquisition and other CPU operations that do not use WideField3, depending on the
combination of various access routes and CPU operation permission groups.
SEE ALSO
For the CPU operation restriction function (operation protection), refer to "A6.22.8 CPU Operation
Restriction" of “Sequence CPU Instruction Manual - Functions (for F3SP71-4N/4S,F3SP76-7N/7S)”
(IM 34M06P15-01E).
To Next Page
