3.5 Write Single Coil ($05)

Writes the value (either 1 or 0) to a single coil.

The amount of devices that can be accessed with a single request is one point.

Request Format (Master => Slave)

F030105.VSD

Function Code

Data

$05

1-byte 2-byte 2-byte

Coil Nos.

($0000 to $FFFF)

Specified Value

1:$FF00

0:$0000

Response Format (Slave => Master)

(At Normal Completion)

(At Faulty Completion)

Function Code

Data

$85

1-byte

Error Code

1-byte

Function Code

Data

$05

1-byte

2-byte

Coil Nos.

(Same Value as Request)

Specified Value

(Same Value as Request)

The slave returns the request received from the master with no change.
