YOKOGAWA F3SP71-4S User Manual

2-9
IM 34M06P15-03E 2nd Edition: Jan. 31, 2012-00
zInput Register
Special registers (Z) are associated with input registers.
Input Registers
（00001 to 65536）
F020603.VSD
Special Registers
Z
(Z00001 to Z01024)
01024
65536
00001
01025
Figure 2.6.3 Associations of Input Registers with Special Registers (Z)
Z00001 is associated with 00001 of the input registers.
The input register device number associated with a special register is calculated using
the following formula.
Input register device number = Special register number
Tip
$0000 is used in the PDU for specifying the input register number 00001 corresponding to Z00001.
