YOKOGAWA FLXA202

24
IM 12A01A02-12E 9th Edition : Mar. 23, 2018-00
(Note) The universal mounting kit (/UM) contains the pipe and wall mounting hardware (/U) and the panel
mounting hardware (/PM).
Panel mounting hardware (Option code: /PM, /UM)
2-M5 length 35
185
178
100
195
121
Panel thickness
1 to 12
Spacing panel cutout
4-M6 *
138
+1
0
138
+1
0
FB4-202_02.ai
Unit: mm
*: Tighten the four screws to a torque of 2 N•m.
Wall mounting hardware (Option code: /U, /UM)
165
168
13
100
70
165
234.5
200
50
15
For wall mounting
3-ø10 holes
4-M6 *
FB4-202_03.ai
Unit: mm
*: Tighten the four screws to a torque of 2 N•m.
Note: The wall on which the analyzer is mounted should be strong enough to bear the weight of more than 8 kg.
