20
IM 04L55B01-02EN
Wiring to a GX90WD Digital I/O Module
Terminal Diagram
301/201/101
DI
DO
302/202/102
310/210/110
Terminal Diagram
Wiring direction
303/203/103
305/205/105
DI1 to
DI8
COM
Input type: Photocoupler isolation
Shared common (COM)
Allowable input voltage range:
0 to 10 V
Note:
Do not apply
voltage outside
the allowable
input voltage
range across
input terminals.
Doing so may
damage the GM.
Internal circuit
Terminal Arrangement
CH
No.
Term.
No.
Symbol Term.
No.
Symbol Term.
No.
Symbol
DI1 to
DI8
301 DI3 201 DI2 101 DI1
302 DI6 202 DI5 102 DI4
303 DICOM 203 DI8 103 DI7
304 - 204 - 104 -
DO1 305 DO1NO 205 DO1COM 105 DO1NC
DO2 306 DO2NO 206 DO2COM 106 DO2NC
DO3 307 DO3NO 207 DO3COM 107 DO3NC
DO4 308 DO4NO 208 DO4COM 108 DO4NC
DO5 309 DO5NO 209 DO5COM 109 DO5NC
DO6 310 DO6NO 210 DO6COM 110 DO6NC
Wiring to a GX90XP Pulse Input Module
Terminal Diagram
CH1
+
+
+
+
+
+
+
+
+
+
+
+
+
+
+
+
+
+
+
+
CH2
CH3
CH4
CH5
CH1
CH2
CH3
CH4
CH5
CH6
CH7
CH8
CH9
CH10
CH6
CH7
CH8
CH9
CH10
(11)
(20)
(11)
(20)
(21)
(30)
(21)
(30)
M3 screw terminal Clamp terminal
Wiring direction Wiring direction
Terminal Arrangement
Term. No. Symbol Term. No. Symbol
21 CH6 + 11 CH1 +
22 12
23 CH7 + 13 CH2 +
24 14
25 CH8 + 15 CH3 +
26 16
27 CH9 + 17 CH4 +
28 18
29 CH10 + 19 CH5 +
30 20
+
5 V DC
Approx. 5kΩ
Input type: Photocoupler isolation
Negative terminal (common)
potential shared
Allowable input voltage range: ±10 V
Note: Do not apply voltage outside
the allowable input voltage
range across input terminals.
Doing so may damage the GM.
Internal circuit
Wiring to a GX90YA Analog Output Module
Terminal Diagram
M3 screw terminal Clamp terminal
CH1
+
+
+
+
+
+
+
+
CH2
CH3
CH4
CH1
CH2
CH3
CH4
Wiring direction Wiring direction
(11)
(18)
(11)
(18)
Terminal Arrangement
CH
No.
Term.
No.
Symbol
CH1
11 +
12 -
CH2
13 +
14 -
CH3
15 +
16 -
CH4
17 +
18 -
19 ---
20 ---
Wiring to a GX90UT PID Control Module
Terminal Diagram
M3 screw terminal
Wiring direction
DI
AI
AO
DO
301/201/101
302/202/102
303/203/103
304/204/104
305/205/105
306/206/106
307/207/107
308/208/108
209/109
210/110
