YOKOGAWA MT300 Adjustment Manual

9/12IM MT300-71EN
CALibrate Group
:CALibrate:DA:ADJust:MFULl
Function Sets the full-scale negative adjustment value of
the D/A output.
Syntax
:CALibrate:DA:ADJust:MFULl <
Voltage
>
<Voltage> =
5 V range
 −4.00000(V)to−6.00000(V)(0.00001Vsetting
resolution)
2 V range
 −1.60000(V)to−2.40000(V)(0.00001Vsetting
resolution)
Example
:CALIBRATE:DA:ADJUST:MFULL −5.00000V
Description • Onmodelswithoutthe/DAoption,a“241:
Hardwaremissing”errorwilloccur.
• Use the
:CALibrate:FUNCtion
command in
advance to set the adjustment target to DA. If
theadjustmenttargetisnotDA,a“221:Setting
conflict”errorwilloccur.
• Use the
:CALibrate:DA:POINt
command
to set the adjustment point to MFULL. If the
adjustmentpointisnotMFULL,a“221:Setting
conflict”errorwilloccur.
:CALibrate:DA:ADJust:PFULl
Function Sets the full-scale positive adjustment value of
the D/A output.
Syntax
:CALibrate:DA:ADJust:PFULl <
Voltage
>
<Voltage> =
5 V range
4.00000(V)to6.00000(V)(0.00001Vsetting
resolution)
2 V range
1.60000(V)to2.40000(V)(0.00001Vsetting
resolution)
Example
 :CALIBRATE:DA:ADJUST:PFULL5.00000V
Description • Onmodelswithoutthe/DAoption,a“241:
Hardwaremissing”errorwilloccur.
• Use the
:CALibrate:FUNCtion
command in
advance to set the adjustment target to DA. If
theadjustmenttargetisnotDA,a“221:Setting
conflict”errorwilloccur.
• Use the
:CALibrate:DA:POINt
command
to set the adjustment point to PFULL. If the
adjustmentpointisnotPFULL,a“221:Setting
conflict”errorwilloccur.
:CALibrate:DA:ADJust:ZERO
Function Sets the zero point adjustment value of D/A
output.
Syntax
:CALibrate:DA:ADJust:ZERO <
Voltage
>
<Voltage> =
5 V range
−0.50000(V)to0.50000(V)(0.00001Vsetting
resolution)
2 V range
−0.20000(V)to0.20000(V)(0.00001Vsetting
resolution)
Example
:CALIBRATE:DA:ADJUST:ZERO 0.10000V
Description • Onmodelswithoutthe/DAoption,a“241:
Hardwaremissing”errorwilloccur.
• Use the
:CALibrate:FUNCtion
command in
advance to set the adjustment target to DA. If
theadjustmenttargetisnotDA,a“221:Setting
conflict”errorwilloccur.
• Use the
:CALibrate:DA:POINt
command
to set the adjustment point to ZERO. If the
adjustmentpointisnotZERO,a“221:Setting
conflict”errorwilloccur.
:CALibrate:DA:DATE?
Function Queries the date when the adjustment value of D/
A output was written.
Syntax
:CALibrate:DA:DATE?
Example
:CALIBRATE:DA:DATE?
-> :CALIBRATE:DA:DATE "2019/09/12"
Description Onmodelswithoutthe/DAoption,a“241:
Hardwaremissing”errorwilloccur.
:CALibrate:DA:INITialize
Function Initializes the adjustment value of D/A output.
Syntax
:CALibrate:DA:INITialize
Example
:CALIBRATE:DA:INITIALIZE
Description • Initializes the adjustment value of D/A output.
Onmodelswithoutthe/DAoption,a“241:
Hardwaremissing”errorwilloccur.
• Use the
:CALibrate:FUNCtion
command in
advance to set the adjustment target to DA. If
theadjustmenttargetisnotDA,a“221:Setting
conflict”errorwilloccur.
