■ External Dimensions and Panel Cutout Dimensions
(25)
(53)
[(N-1)96+92]117 min.
145 min.
+0.8
0
+0.8
0
92
+0.8
0
92
+0.8
0
92
"N" stands for the number of controllers to be
installed.
However, the measured value applies if N  5.
100
11
UM350
General installation Side-by-side close installation
1 to 10 mm (Panel thickness)
Small bracket
Large bracket
91.8
112
Unit: mm
96
96
48
UM330
96
10011
1 to 10 mm (Panel thickness)
Small bracket
Small bracket
91.8
112
Unit: mm
145 min.
General installation
Front of indicator
(53)
(25)
70 min.
+0.8
0
92
+0.6
0
45
