1. Installation
This chapter describes installation, wiring, and other tasks required to make the
controller ready for operation.
1.1 Model and Suffix Codes
Before using the controller, check that the model and suffix codes match your order.
UT351
UT321
0 None
1 With communication, heater burnout alarm
Optional functions
2 With heater burnout alarm
-0 Standard type
-2 Heating/cooling type
Standard type (with 24 V DC loop power supply)-3
Digital indicating controller (provided with retransmission output and 15 V
DC loop power supply as standard)
Model Suffix Code Description
Type
Check that the following items are provided:
• Digital indicating controller (of ordered model)...................... 1
• Brackets (mounting hardware) ............................................. 1 pair
• Unit label.............................................................................. 1
• User’s Manuals .................................................................... 3 (A2 size)
• User’s Manuals
“Setting/Explanation of Active Color PV Display ................... 1 (A3 size)
• User’s Manual (Reference) (CD-ROM version) .................... 1
